步距角 Step Angle

0.9°

步距角精度 Step Angle Accuracy

±5% (full step, no load)

電阻公差 Resistance Accuracy

±10% @20℃

電感公差 Inductance Accuracy

±20% @1kHz

溫升 Temperature Rise

80℃ Max.(rated current)

環(huán)境溫度 Ambient Temperature

-20℃~+50℃

絕緣電阻 Insulation Resistance

100MΩMin. ,500VDC

介電強度 Dielectric Strength

500VAC for one minute

徑向間隙 Shaft Radial Play

0.02Max. (450 g-load)

軸向間隙 Shaft Axial Play

0.08Max. (450 g-load)

V

A

Ω

mH

g. cm

g-cm2

kg

mm

42HS34M-1334A

2.8

1.33

2.1

4.2

2200

4

35

0.22

34

42HS40M-1206A

4

1.2

3.3

4

2500

6

54

0.28

40

42HS40M-1684A

2.8

1.68

1.65

3.2

3300

4

54

0.28

40

42HS47M-1206A

4

1.2

3.3

4

3100

6

68

0.35

47

42HS47M-1684A

2.8

1.68

1.65

4.1

4400

4

68

0.35

47
